- Processing Speed, Accuracy Improvement

- Parallel Operation Function ( Up to 8 sets of transformer)

- Real-time Monitoring Function

- 7inch TOUCHLCD

- Protection elements mounted

- Tap Operating function

- Hourly Operating function

- IEC61850 Communication
   (KEMA Certification : No.74101864- MOC/INC 12-01-490)

Product

The Product is automatic voltage regulator to operate the On Load Tap Changer(OLTC) on main transformer. It can control the voltage according to each load characteristics and can supporting parallel operation up to 8 sets of transformer without any additional devices and also, it can IEC 61850 Communication. So, This product is suitable for the digital substation.

Features

1. Processing Speed,    Accuracy Improvement	- Adopt the 32bit Digital Signal Processor - Possible to measure 0.1V and 0.01A By 16Bt A/D Convertor
2. Parallel Operation    Function	- Parallel aperation methods : Master/Foller and CRC method - Possible to support parallel operation up to 8 sets of transformer
3. Real-time Monitoring    Function	- Display LED and output alarm signal case error occurs
4. 7" TOUCH LCD	- Providing the convenience of the user operation
5. Protection elements    mounted	- OCR(50), OVR(59), UVR(27) Protection elements mounted
6. Tap Operation of OLTC    Counting Function	- Court and record the number of tap operation - Possible to forecast the maintenance time for on load tap changer
7. Hourly Operating function	- Operation Mode supports 8 - Possible to Weekdays weekend driving mode setting
8. IEC 61850 Communication	- Offer MMS, Goose, Report signals - Reliability secure through communication redundancy - Other Company IED interoperability

Specification

Control Power Source		AC 80V~264 OR DC 110~340V
Power Consumption		Under 30W at normal time, Under 50W at during operation
Related	Current	AC 5A
	Voltage	AC 110V
Input	Current	1EA
	Voltage	1EA
	Digital	22EA
	Analog	4EA
Output	Control	10EA( ‘a’ Cotact)
	Alarm	10EA('a' Cotact)
	4~20mA	4EA
Communication	Front	RS - 232(Front HMI)
	Back side	OPTIC PORT(ST TYPE) x 4EA (for IEC 61850 : 2EA, OPTION : 2EA) LAN PORT ×1EA(for IEC 61850)
Case	Material	Steel
	Size	322 x 308 x 216 mm
